SwissTech: M8X1.25 Or. Sp/Pt 371 HSS-PM NIT+OX Tap Spiral Point/Gun Nose - ISO Metric Coarse HSS-PM Nitride & Oxide Finish. For through holes. Taper lead to DIN form B (3.5 x P to 5.5 x P). Tapping tolerance to 6HX. MPN: 5036140209381 EAN: 5036140209381 M8X1.25 Or. Sp/Pt 371 HSS-PM NIT+OX Tap Attributes: Class of Fit: 6HX Coolant Delivery: External Dimensions Standard: DIN 371 Finish/Coating: Nitride Steam Tempered Material: Powdered Metal High Speed Steel Material Application: Titanium Alloys Nickel High-temperature Alloys Material Grade: HSS-PM Number of Flutes: 3 Overall Length: 90.0mm Pitch: 1.25 Ring Colour: Orange Shank Diameter: 8.00mm Square Width: 6.20mm Tap Type: Spiral Point Thread Direction: Right Hand Thread Length: 22.00mm Thread Size: M8 Thread Standard: Metric Coarse
