EX00 M4X0.70 hss-e Spiral Flute Machine Tap - DIN371 - Dormer

EX00 M4X0.70 hss-e Spiral Flute Machine Tap - DIN371 - Dormer
Brand: DORMER
24.71 GBP
Buy Now

Dormer: EX00 M4X0.70 HSS-E Spiral Flute Machine Tap - DIN371 EX00 HSS-E PM Spiral Flute Taps Metric Form Multi-application machine taps offering superb performance in a wide range of materials 2.5xD Available in a choice of finishes: Bright, Steam Tempered or Titanium Nitride Coated (TiN) Spiral Flute for blind holes EX00 available in sizes M2 - M64 Manufactured to DIN 371 12mm Bright Finish - Suitable for Steel, Cast Iron, Titanium, Nickel, Copper and Aluminium MPN: 7320760136614 EAN: 7320760136614 EX00 M4X0.70 HSS-E Spiral Flute Machine Tap - DIN371 Attributes: Class of Fit: 6H Dimensions Standard: DIN 371 Finish/Coating: Bright Helix Angle: 45° MFR Part No.: EX00M4 Material: Powdered Metal Cobalt High Speed Steel Material Grade: M35 Number of Flutes: 3 Overall Length: 63.00mm Pitch: 0.7 Series: EX006H Shank Diameter: 4.5mm Square Width: 3.40mm Tap Type: Spiral Flute Tapping Depth: 21.00mm Thread Direction: Right Hand Thread Length: 7.0mm Thread Size: M4 Thread
